Transformations of trigonometric functions

We have seen what the standard graphs of sine and cosine look like. We can also transform these functions.

Transformations

We can transform the functions #f(x)=\sin(x)# and #g(x)=\cos(x)# in four ways. We will show these using the sine function, but the cosine works in the same way.

	Transformations	Examples
1	We shift the graph of #f(x)=\sin(x)# up by #\green q#. The new function becomes \[f(x)=\sin(x)+\green q\] The period and amplitude of the function remain the same, but the equilibrium becomes equal to #\green q#.	Plaatje verticale translatie
2	We shift the graph of #f(x)=\sin(x)# to the right by #\blue p#. The new function becomes \[f(x)=\sin\left(x-\blue p\right)\] The period, amplitude and equilibrium remain the same. We call #\blue p# the phase shift.	Plaatje horizontale translatie
3	We multiply the graph of #f(x)=\sin(x)# by #\purple a# relative to the #x#-axis. The new function becomes \[f(x)=\purple a \sin(x)\] The period and equilibrium remain the same, but the amplitude becomes equal to #\purple{\left\| a \right\|}#. When #\purple a \lt 0#, the graph reverses. This means it first falls instead of rises. If #\purple a =- 1#, the new function is a reflection of the old function across the #x#-axis.	Plaatje vermenigvuldiging x-as
4	We multiply the graph of #f(x)=\sin(x)# by #\orange b# relative to the #y#-axis. This means we replace #x# with #\frac{1}{\orange b}x#. The new function becomes \[f(x)=\sin\left(\frac{1}{\orange b}x\right)\] The equilibrium and amplitude remain the same, but the period becomes equal to #\orange b \cdot 2 \pi#.	Plaatje vermenigvuldiging #y#-as.

More transformations

We can also perform multiple transformations in succession.

For example: #f(x)=\purple3 \sin\left(x-\blue4\right)# is at first a shift to the right by #\blue4#, and subsequently a multiplication by #\purple3# relative to the #x#-axis of the trigonometric function #f(x)=\sin(x)#.

Compose sine and cosine function

The standard sine function has the form #f(x)=\purple a \sin(\tfrac{1}{\orange b}(x-\blue p))+\green q#.

This function has period #\orange b \cdot 2 \pi#, amplitude #\purple a#, equilibrium #\green q# and phase shift #\blue p#. The latter means that at #x=\blue p# the graph of the sine function rises through the equilibrium.

The same applies to the cosine function. The standard cosine function is #f(x)=\purple a \cos(\tfrac{1}{\orange b}(x-\blue p))+\green q#.

This function has period #\orange b \cdot 2 \pi#, amplitude #\purple a#, equilibrium #\green q# and phase shift #\blue p#. The latter means that at #x=\blue p# the cosine function has a top (with #y#-value #\purple a + \green q#).

We note that we can obtain the cosine by translating the sine. Earlier, we saw that \[\cos(x)=\sin(x+\frac{\pi}{2})\]

Take another look at the two graphs.

The blue (solid) graph has formula:
\[y=\sin \left(x\right)\]
What is the formula of the green (dashed) graph?

#y=# #\sin \left(x\right)-5#

In step 1 we saw that the green graph is obtained by shifting the blue graph downwards by #5#. Hence, we subtract #5# from the formula of the blue graph #y=\sin \left(x\right)#. This gives us the following formula for the green graph:
\[y=\sin \left(x\right)-5\]
